180 度立式带缺口 RJ45 网络连接器，百兆内置集成磁环
180 Degree with Notch, Vertical RJ45 Network Connector, 100Mbps Integrated Magnetics
180 度立式带定位缺口 RJ45 屏蔽网口，外壳预留定位缺口，便于 PCB 精准对位安装；内置一体式百兆隔离滤波磁环，支持 10/100Mbps 自适应百兆以太网传输；端口搭载绿色、黄色双 LED 指示灯，分别实时显示链路连通与数据收发状态；全包金属屏蔽外壳搭配侧边接地弹片，有效阻隔外界电磁干扰，保障信号稳定传输；8P8C 接触针脚加厚镀金，耐磨抗氧化，长期反复插拔不易出现接触不良；立式 DIP 直插针脚适配 PCB 波峰焊工艺，内部耐高温阻燃塑胶，结构紧凑节省线路板空间；广泛适配百兆交换机、家用路由器、工控主板、小型安防监控设备；标准装箱 1100PCS / 箱，交期 3-7 个工作日，符合 RoHS 环保认证。
180-degree vertical shielded RJ45 jack with positioning notch on housing for accurate PCB alignment during installation. Built-in integrated fast ethernet isolation magnetic ring, supporting 10/100Mbps adaptive 100M network transmission. The port is equipped with independent green and yellow dual LED indicators to display link connection and data transmission status in real time. Full metal shielding shell with side grounding springs effectively blocks external electromagnetic interference to ensure stable signal transmission. Thick gold-plated 8P8C contact pins are wear-resistant and anti-oxidation to avoid poor contact after long-term repeated plugging. Vertical DIP through-hole pins are compatible with PCB wave soldering process. The inner housing adopts high-temperature resistant flame retardant plastic, and the compact structure saves PCB layout space. Widely applied to 100M switches, household routers, industrial control mainboards and small security monitoring equipment. Standard packing: 1100 PCS per carton, lead time 3-7 working days, RoHS compliant.
Q1：这款 RJ45 连接器插板角度、外壳特征与传输规格是什么？
180 度立式 PCB 插板，外壳带定位缺口，内置百兆集成磁环，支持 10/100Mbps 自适应百兆网络传输。
What are the PCB mounting angle, shell features and transmission specifications of this RJ45 connector?
180-degree vertical PCB mounting, positioning notch on shell, built-in 100Mbps integrated magnetic ring, supporting 10/100Mbps adaptive fast ethernet transmission.
Q2：产品指示灯配置与屏蔽结构优势？
端口配备绿、黄双色独立 LED 状态指示灯；全包金属屏蔽外壳搭配接地弹片，抗电磁干扰性能优异。
What are the indicator light configuration and advantages of shielding structure of the product?
The port is equipped with independent green and yellow dual LED status indicators; the full metal shielding shell with grounding springs delivers excellent anti-electromagnetic interference performance.
Q3：适配哪种 PCB 焊接工艺？
立式 DIP 直插针脚设计，适配 PCB 波峰焊批量焊接加工。
Which PCB soldering process is it compatible with?
Designed with vertical DIP through-hole pins, suitable for mass PCB wave soldering processing.
