中文：1.0mm 间距 FPC 连接器 抽屉式立贴一字脚 FFC 扁平排线插座 4P-30P
English: 1.0mm Pitch FPC Connector Drawer Type Vertical SMT Straight Pin FFC Flat Cable Socket 4P-30P
产品描述（中英双语）
中文
1.0mm 间距抽屉式 FPC 连接器，立贴一字脚贴片结构，针位覆盖 4P~30P 齐全规格。耐高温绝缘基座，磷青铜镀金触点，接触稳定抗氧化；抽屉锁扣结构牢固锁紧 FFC 扁平排线，不易松脱。适配 SMT 回流焊工艺，广泛应用显示屏、数码设备、工控主板、家电控制板排线连接，常规规格现货供应，支持试样与定制。
English
1.0mm pitch drawer-lock FPC connector, vertical SMT straight pin design, pin count available from 4P to 30P. High-temperature resistant base with gold-plated phosphor bronze contacts for stable connection and oxidation resistance. Drawer locking mechanism firmly secures FFC flat cables to prevent loose contact. Compatible with SMT reflow soldering. Widely used for display screens, digital products, industrial control boards and home appliances. Standard models in stock, samples and customization are supported.
FAQ 中英双语
Q1：连接器间距以及可用针位是多少？
A1：间距 1.0mm，规格 4P、6P、8P、10P 至 30P 均可供货。
Q1: What is pitch and available pin counts?
A1: 1.0mm pitch, options from 4P,6P,8P,10P up to 30P.
Q2：安装方式与锁扣类型是什么？
A2：立贴一字脚贴片，抽屉式前锁结构。
Q2: Mounting type and lock style?
A2: Vertical SMT straight pin, front drawer lock type.
Q3：能否过 SMT 回流焊？
A3：塑胶耐温达标，支持标准 SMT 回流焊接。
Q3: Can it pass SMT reflow soldering?
A3: Yes, heat-resistant housing fits standard reflow process.
Q4：适配线材类型？
A4：匹配 1.0mm 间距 FFC/FPC 扁平软排线。
Q4: Which cable does it fit?
A4: Suitable for 1.0mm pitch FFC/FPC flat flexible cables.
Q5：可以申请样品吗，批量交期多久？
A5：支持样品申请，常规规格现货，批量交期稳定。
Q5: Can I get samples? Bulk lead time?
A5: Samples available, regular items in stock with stable delivery.
